project overview

Vessel Type: RoRo

Vessel Name: 8,600 CEU DF PCTC

Scope of work
  • Concept Design
Project specification

Download specification

The vessel is developed around the Sleipner concept having the declared target of lowest fuel consumption per transported cargo.

The low fuel consumption is primarily obtained by:

  • a high payload to displacement ratio, due to a low and lightweight design and “Zero WB”.
  • hull optimization for effective working range, includes optimum positioning of LCB
  • highly optimized engine – propeller – hull interaction
  • low wind resistance
  • machinery such as shaft generator, battery package, Eco EGR and more

Optimization of the design, incl. hull, ramp arrangement, deck lay out etc, has been optimized for payloads of 8,000 t – 15,000 t with a corresponding DWT of 10,500 t – 20,000 t. Design condition is based on homogenous stowed payload.
